XBD-JS Series Long Shaft Deep Well Pumps

Product Introduction
This product is developed based on the characteristics of key fire prevention units such as substations, oil depots, oil terminals, and oil drilling platforms, which lack a large amount of tap water supply and occupy a small area. It adopts excellent hydraulic models and advanced structural design concepts at home and abroad, and has the characteristics of high efficiency, wide application range, safe and reliable operation, and fast start-up. This water pump is used to transport clean water and seawater with a temperature below 55 ℃.

Structural Characteristics
Advanced hydraulic models and structural designs are selected, and various new processes such as Ashland process for core making and epoxy coating for blade flow channels are adopted. The material selection is reasonable, the product performance is excellent, and the service life is achieved by using a sand throwing ring device. The labyrinth structure prevents sand particles from entering the bearing.
The impeller shaft and motor shaft are supported by copper bearings, and the radial runout of the shaft is controlled within 0.13mm according to the American standard. The pump runs smoothly with low noise.
The pump seat has a beautiful design and a large window, making it easy to maintain and replace the packing.
Choose ductile iron ASTM304、 Various grades of stainless steel materials such as 316 and 416 are used to meet users' special operating conditions and technical requirements.

Characteristics of 3C certified fire pump
Flow rate: 1-200L/s
Lift: 50-185m
Speed: 2900r/min
