XBD-GDL Vertical Multi-stage Fire Pump

Product Overview
The performance parameters and technical conditions of the XBD-GDL series vertical multi-stage fire pump assembly comply with the national standard GB6245-2006 "Fire Pump" and have obtained the 3C certification issued by the fire department. It can be used to transport clean water or liquids with physical and chemical properties similar to water that do not contain solid particles, as well as slightly corrosive liquids. The flow rate range for transporting liquids is 1~45L/s, the pressure range is 0.3~2.0MPa, the matching power range is 5.5~132kw, and the diameter range is φ 40~φ 150mm.
Purpose
XBD-GDL series vertical multi-stage fire pump sets are mainly used for fixed firefighting systems in industrial and civil buildings (fire hydrant extinguishing systems, water sprinkler extinguishing systems, water spray extinguishing systems, and other common firefighting systems). It is also suitable for the circulation and pressurization of hot and cold clean water in high-pressure operating systems, parallel water supply of multiple pumps in high-rise buildings, boiler feedwater and cooling water systems, and the transportation of various flushing liquids.
Characteristics of 3C-certified fire pump
Stainless steel 304 precision cast impeller, stainless steel shaft, using anti-corrosion materials, the product will not get stuck due to rust; QT400-18 casting pump body, pump cover, Sic wear-resistant mechanical seal, high standard materials make the product durable; Imported with built-in vacuum pressure gauge, and exported with built-in pressure gauge to monitor inlet and outlet pressure at any time; Cast steel coupling, stainless steel 304 coupling protective cover, can provide both safe protection and beautiful appearance.
